The Ubiquiti UniFi 24-Port PoE Switch (USW-24-PoE) is a fully managed switch with (24) GbE RJ45 ports, including (16) GbE, 802.3at PoE+ ports, and (2) 1G SFP ports. The versatile USW 24 PoE provides Gigabit PoE links to Ethernet devices while also supplying Gigabit fiber uplink options fit for an enterprise network. The switch also offers an extensive suite of Layer 2 switching protocols, including port-specific operation modes (switching, mirroring, or aggregate), and features a 1.3″ LCM color touchscreen that concisely displays key system and connection insights.

Additionally, with its 7.9″ depth, it’s easy to mount this compact, fanless switch in a SOHO rack cabinet. This switch can also be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.

Features:

• (1) 1.3″ LCM color touchscreen with AR switch management
• (16) GbE, 802.3at PoE+ RJ45 ports
• (8) GbE RJ45 ports
• (2) 1G SFP ports
• 95W total PoE supply
• Fanless, silent cooling

Scalable UniFi Network Controller

Management Capabilities

The UniFi Network Controller can provision UniFi devices, map
out networks, and quickly manage system traffic. Important
network details are logically organized for a simplified, yet
powerful, interface.

Network Overview

From a single pane of glass, view network topology and
configuration, real‑time statistics, and debugging metrics. Monitor
your network’s vitals and make on‑the‑fly adjustments as needed.
Deep Packet Inspection
Ubiquiti’s proprietary Deep Packet Inspection (DPI) engine includes
the latest application identification signatures to track which
applications (and IP addresses) are using the most bandwidth.

Detailed Analytics

The UniFi Network Controller provides configurable reporting
and analytics to manage large user populations and expedite
troubleshooting. Advanced search and sorting capabilities make
network management more efficient.

Multi-Site Management

A single controller running in the cloud can manage multiple
sites: multiple, distributed deployments and multi‑tenancy for
managed service providers. Each site is logically separated and
has its own configuration, maps, statistics, guest portal, and
administrator accounts.

Switch Configuration

You can access any managed UniFi Switch through the UniFi
Controller to configure a variety of features:
• Operation mode (switching, mirroring, or aggregate) per port
• Network/VLAN configuration
• Jumbo frame and flow control services
• Network settings
• Storm control setting per port
• Spanning tree configuration
• 802.1X control and RADIUS VLAN
• Debug terminal option for command‑line interface

Switch Port Status

You can also view status information for each port:
• Connection speed and duplex mode
• TX/RX data rates
• Network/VLAN settin

Software Features

The UniFi Network Controller software offers the following features:
• Centralized configuration management (including configuration
cloning)
• Auto‑MDIX automatically adjusts as needed for straight through
or crossover cable
• 802.1X (RADIUS) authentication and dynamic VLAN.
